Ricoh C252 - Drive Layout

MECHANISM OVERVIEW
SM 6-5 C252
Detailed
Descriptions
6.1.3 DRIVE LAYOUT
1. Master Eject Motor
2. Scanner Motor
3. Pressure Plate Motor
4. Clamper Motor
5. Main Motor
6. Registration Motor
7. Master Feed Motor
C252D004.WMF
3
4
5
6
7
2 1
