SERVICE PROGRAM MODE
SM 5-3 C252
Service
Tables
5.1.3 MAIN MENU NO.2: OUTPUT MODE
No. Name Note
2-3 Master Eject Motor
2-6 Vacuum Fan Motor
2-7 Air Knife Fan Motor
2-9 Master Counter
2-10 Paper Counter
2-12 Ink Pump Motor
2-14 Pressure Release Solenoids
2-21 Exposure Lamp (Xenon Lamp)
2-22 Cutter Motor: + direction
2-23 Cutter Motor: to Home
2-24 Cutter Motor: - direction
2-27 Main Motor: to drum home position
2-28 Main Motor: to master making position
2-36 Master Feed Motor
2-37 Scanner Motor
2-41
Thermal Head Signal Output (VHD Signal)
"5.1.4
2-42 Paper Feed Clutch
2-44 Clamper Motor: to close
2-45 Clamper Motor: to open
2-46 Pressure Plate Motor: to limit
2-47 Pressure Plate Motor: to home position
2-48 Main Motor: 30rpm
2-49 Main Motor: 60rpm
2-50 Main Motor: 90rpm
2-51 Paper Feed Motor: 30rpm
2-52 Paper Feed Motor: 60rpm
2-53 Paper Feed Motor: 90rpm
Press and hold the master making
key to start the test. Release the key
to stop the test.
5.1.4 SP2-41: THERMAL HEAD SIGNAL OUTPUT (VHD SIGNAL)
Applies thermal head voltage.
Power is applied by pressing the # key. To protect the thermal head, the voltage
supply is automatically stopped after 30 seconds. It is also stopped by pressing the
clear/stop key.
"3.5.3
