INSTALLATION REQUIREMENTS
C252 1-2 SM
1.1.4 MINIMUM SPACE REQUIREMENTS
Place the machine near a power source, providing minimum clearance as shown
below.
1.1.5 DIMENSIONS
C252I010.WMF
C252I014.WMF
C252I013.WMF
600 mm (23.6") Front
600 mm (23.6") Right 600 mm (23.6") Left
200 mm (7.9") Rear
1232 mm (48.5")
582mm (23.0")
519 mm (20.5")
663 mm (26.1")
