Ricoh C252 - Registration Sensor Cleaning

PAPER FEED
C252 6-28 SM
6.7.5 REGISTRATION SENSOR CLEANING
NOTE: This mechanism is attached only for the China model.
Dust on the registration sensor [A] can be removed by operating a lever [B]. The
technician should do this every visit.
C252D029.WMF
[A]
[B]
