PRINTING
SM 3-21 C252
Replacement
and
Adjustment
3.8.4 PRINTING PRESSURE ADJUSTMENT
Purpose: To make better print results without decreasing the run length.
Standard: Within 10 ± 0.5 mm
• Paper delivery unit (! 3.10.1)
1. Adjust the distance [A] to 10 ± 0.5 mm by turning the adjusting bolt [B].
2. Repeat the same procedure for the printing pressure spring at the non-
operation side.
C252R023.WMF
[A]
[B]
