Ricoh C252 - Paper Delivery; Overview

PAPER DELIVERY
C252 6-32 SM
6.8 PAPER DELIVERY
6.8.1 OVERVIEW
Procedure
The exit pawl [A] and the air knife [B] separate the paper from the drum.
↓
The paper is fed to the paper delivery table [C] by the paper delivery unit [D].
The paper exit sensor [E] is used for jam detection. (!4.4.6)
C252D027.WMF
[A]
[B]
[C]
[D]
[E]
