INSTALLATION PROCEDURE
C252 1-6 SM
6. Open the master making unit cover, and insert the leading edge of the master
roll under the platen roller. The arrows [A] indicate the correct position of the
master leading edge.
7. Close the master making unit cover [B] using both hands until it clicks into
place.
8. Close the right side cover.
C252I019.WMF
C252I020.WMF
[A]
[B]
