Ricoh DSm651 - Installing the Postscript 3 Printer Driver (Windows 95;98;Me - IPP)

Using the SmartDeviceMonitor for Client Port
5
1
Installing the PostScript 3 Printer Driver (Windows 95/98/Me - IPP)
A
AA
A
Quit all applications currently running.
B
BB
B
Insert the CD-ROM into the CD-ROM drive.
The installer starts.
Auto Run may not work with certain operating system settings. If this hap-
pens, launch “Setup.exe” on the CD-ROM root directory.
C
CC
C
Select an interface language, and then click [OK].
The default interface language is English.
Note
❒ The printer driver with the selected language will be installed. The printer
driver will be installed in English if you select the following languages:
Cestina, Magyar, Polski, Portugues, Suomi
D
DD
D
Click [PostScript 3 Printer Driver].
Add Printer Wizard starts.
E
EE
E
Click [Next].
F
FF
F
Click [Local Printer], and then click [Next].
A dialog box for selecting the printer manufacturer and model name appears.
G
GG
G
Select the name of the machine whose driver you want to install, and then
click [Next].
H
HH
H
In the [Available ports:] box, click [Printer Port], and then click [Next].
I
II
I
Change the printer name if you want, and then click [Next].
Select the [Yes] check box to configure the printer as default.
J
JJ
J
Specify whether or not to print a test page, and then click [Finish].
K
KK
K
On the [Start] menu, point to [Settings], and then click [Printers].
The [Printers] window appears.
L
LL
L
Click the icon of the printer you want to use. On the [File] menu, click [Prop-
erties].
M
MM
M
On the [Details] tab, click [Add Port…].
N
NN
N
Click [SmartDeviceMonitor] in the [Other] list, and then click [OK].
O
OO
O
Click [IPP].
