SPECIFICATIONS 31 October 2001
SPEC-2
Power Consumption:
Mainframe Only
120 V 220 ~ 240 V
Copying 60 rpm
Not above
170 W
Not above
170 W
Copying 90 rpm
Not above
190 W
Not above
190 W
Copying 120 rpm
Not above
220 W
Not above
215 W
Master making
Not above
160 W
Not above
160 W
Standby (Energy
saver mode)
Not above
5 W
Not above
8 W
Noise Emission
Sound Power Level Operating Position Sound Power Level
Standby: Not above 48 dB(A) Not above 35 dB(A)
Copying 60 rpm: Not above 74 dB(A) Not above 60 dB(A)
Copying 90 rpm: Not above 78 dB(A) Not above 63 dB(A)
Copying 120 rpm: Not above 81 dB(A) Not above 66 dB(A)
NOTE: The above measurement made in accordance with ISO 7779 are actual
value.
Dimensions (W x D x H)
Tables closed: 790 x 700 x 640 mm (31.1" x 27.6" x 25.2")
Tables opened: 1360 x 700 x 600 mm (53.6" x 27.6" x 25.2")
NOTE: Measurement Conditions
1) Without the ADF
2) Without the table
Weight
80 kg (176.6 lb)
(Excluding ADF, platen cover, ink, and master)
