SC No. Level Error Name/Error Condition/Major Cause/Solution
SC396-05 D Drum motor (CMY) Lock
Lock signals are observed at 2 sec intervals during motor ON, and a
High level is detected at least 20 times.
• Motor defective
• Connector disconnected
• Harness broken
• IOB defective
• Unit torque increased.
• Replace the motor
• Reconnect the connector
• Replace the harness
• Replace the IOB
• Replace the PCDU
Service Call 324-396
467
