5.
Attach the securing brackets [A] to two positions on the left and right at the rear of the
machine (screws: 1 each).
6.
Return the paper feed tray to the machine
7.
Attach the decals as shown below.
[A]: Tray number decal
[B]: Paper size decal
•
The tray number decal and paper size decal are packaged together with the machine.
Paper Feed Unit PB3210
