2.Replace
ment and
Adjustment
96
2.
Remove
the inner midd
le cover
[A] (
×2).
3.
Remove
the bracket [A]
(
×1).
4.
Remove
the Stapler HP
sensor (S36) [A]
(
×1).
Paper guide HP senso
r (S37)
1.
Remove
the rear cov
er (
Rear Cover
).
101
