Ricoh SR3270 - Paper Exit Sensor (S15); Paper Exit Guide HP Sensor (S35)

2.Replacement and Adjustment
69
2. Remove the Shift Tray Upper Limit Switch (SW2) [A] ( x2, hook × 1).
Paper Exit Sensor (S15)
1. Remove the left center cover (Left Center Cover).
2. Remove the Paper Exit Sensor (S15) [A] (hook ×1, x1, ×1).
Paper Exit Guide HP Sensor (S35)
1. Remove the upper left cover (Upper Left Cover).
