Ricoh SR3270 - Feedout Pawl HP Sensor (S10); Jogger HP Sensor (S11)

2.Replacement and Adjustment
82
2. Remove the Booklet Transport (Upper) Pressure Release HP Sensor (S8) [A] ( ×1).
Feedout Pawl HP Sensor (S10)
1. Remove the stapler tray (Stapler Tray).
2. Remove the Feedout Pawl HP Sensor (S10) [A] ( ×1).
Jogger HP Sensor (S11)
1. Remove the stapler tray (Stapler Tray).
