Ricoh SR3270 - Center-Folding Paper Exit Sensor (S24)

2.Replacement and Adjustment
107
6. Remove the center-folding unit [A] ( ×5).
Center-folding Paper Exit Sensor (S24)
1. Remove the center-folding unit (Center-Folding Unit).
2. Place the center-folding unit with side [A] face up, and then remove the Center-folding Paper Exit
Sensor (S24) bracket.
