Ricoh SR3270 - Intermediate Transport (Right) Sensor (S20); Intermediate Transport (Left) Sensor (S19); Shift Tray Paper Surface Sensor (S13)

2.Replacement and Adjustment
67
Intermediate Transport (Right) Sensor (S20)
1. Remove the upper cover (Upper Cover).
2. Remove the Intermediate Transport (Right) Sensor (S20) [A] ( ×1, ×1).
Intermediate Transport (Left) Sensor (S19)
1. Remove the proof tray (Proof Tray).
2. Remove the Intermediate Transport (Left) Sensor (S19) [A] ( ×1, ×1, ×1).
Shift Tray Paper Surface Sensor (S13)
1. Remove the left center cover (Left Center Cover).
