Ricoh SR3270 - Saddle Stitch Unit

2.Replacement and Adjustment
104
Saddle Stitch Unit
1. Remove the rear cover (Rear Cover).
2. Remove the connectors of main controller board.
3. Remove the stopper [A] ( ×2).
4. Remove the front cover (Front Cover).
