Ricoh SR3270 - Page 25

1.Detailed Descriptions
19
No.
Description
No.
Description
(STM16)
6
Shift Motor (STM1)
17
Paper Guide Drive Motor (STM18)*
7
Entrance Transport Motor (DCM1)
18
Stapleless Stapler Transfer Motor
(STM17)*
8
Junction Gate Solenoid (SOL1)
19
Stapler Transfer Motor (STM6)*
9
Proof Transport Motor (DCM2)
-
-
10
Paper Exit Guide Plate Motor (STM16)
-
-
11
Positioning Roller Motor (STM5)
-
-
* Finisher SR3260 only
