2.8. INFORMATION AND SAFETY SIGNS
The figure indicates the position of the safety and information signs affixed to the machine.
For each sign the relative description is specified.
A)
Warning sign: it indicates that “the battery must be charged in a suitable well ventilated room, outside of the
work environment”.
B)
Prohibition sign: do not act on the component with your hands.
C)
Warning sign: it indicates the component weight.
D)
Danger sign: danger of pole tipping.
E)
Warning sign: it indicates that the accumulator batteries must be charged after a prolonged period of inactivity.
F)
Information sign (applied in transport phase): it provides contraindications and indicates how to prepare the
machine for use after the transport phase.
G)
Information sign (applied in transport phase): it indicates how to remove the pallet from the machine.
H)
Information sign (applied in transport phase): it indicates the conditions for lifting the column.
I)
Information sign: It indicates the lifting points with fork device.
J)
Information sign: It indicates the lifting points with hook device.
Danger - warning
The hook is provided only for lifting the pole during installation.
Do not use it to lift the entire machine.
K)
Electrical hazard sign: do not access the area to avoid risks of electric shock or electrocution.
L)
Information sign: Carefully read the manual before performing any type of intervention.
M)
Prohibition sign: it indicates that the operation must not be performed by more than one person.
N)
Information sign: it indicates that the button is used to unwind the film.
O)
Information sign: it indicates wheel nut tightening direction.
P)
Danger sign: hand crushing danger.
Q)
Information sign: it indicates tyre pressure level.
R)
Danger sign: foot crushing danger.
S)
Danger sign: hand crushing danger.
Important
Make sure that the nameplates are clearly legible.
If not, replace and reposition them at the original position.
