Robopac ROBOT S7 - 3.7. SPOOL TECHNICAL SPECIFICATIONS; 3.7.1. SPOOL FEATURES

36
TECHNICAL INFORMATION
ENG
3.7. SPOOL TECHNICAL SPECIFICATIONS
3.7.1. SPOOL FEATURES
Description
Unit of
measurement
Value
Film reel dimensions (1)
Maximum outer diameter (D)
mm
300
Reel height (H)
mm
500 - 750
2
Film thickness
μm
17÷35
Internal diameter (d)
mm
50
1
- 76
Max. weight
kg
20 - 30
2
Mesh reel dimensions (2)
Maximum outer diameter (D)
mm
300
Reel height (H)
mm
500
Internal diameter (d)
mm
76
Max. weight
kg
20
1
Install the optional reel shaft.
2
Reel option H = 750 mm
