2.10. MACHINE SAFE STOP
Perform the following procedure to safely stop the machine:
1. Move the carriage all the way down;
2. Press the emergency stop button;
3. Open the battery casing (A);
4. Disconnect connector (B);
5. Close the battery casing (A) again.
Danger - warning
Disconnect connectors (B) using the special handle (C).
Do not disconnect connectors directly on the cables as they may be damaged, exposing the operator to the
risk of electric shock.
Danger - warning
Should it not be possible to lower the carriage, the stop at different heights can be considered safe only for
film insertion operations. For the other activities on the carriage, this latter must be kept in the correct
position through the use of external means, such as a support.
Follow the instructions provided in paragraph “Adjustment of the lifting chain of the reel carriage” for the
tensioning of the chain.
