5. INFORMATION ON ADJUSTMENTS
5.1. RECOMMENDATIONS FOR ADJUSTMENTS
- Before performing any operation, the authorised operator must make sure to have understood the “Instructions
for use”.
- Activate one of the safety devices provided, stop the machine and assess whether there is any residual energy
before carrying out the operations.
- Provide suitable safety conditions in compliance with the regulations on workplace safety to prevent and
minimise the risks.
- Pay attention to the safety warnings, do not misuse the machine and assess the possible residual risks.
5.2. “FILM STRETCH” ADJUSTMENT
5.2.1. "FRD for mesh" TYPE REEL CARRIAGES
Proceed as follows.
1.
Work on the handwheel (A) until reaching the value displayed on the index (B).
The brake shaft for mesh is an accessory that can be mounted on the carriage at a later stage.
This optional fitting allows the system to use a mesh reel with a std “FRD” carriage.
Important
For a correct tensioning of the mesh, adjust the braking effect so that the outfeed roller (C) is more braked
than the infeed roller (D); moreover, it is necessary to avoid braking the stretching rollers too much to
prevent the mesh from slipping.
