6.3. DESCRIPTION OF USER INTERFACE
The user interface is equipped with an active matrix “touch screen” colour display.
To view the different functions, just “touch with a finger” the display areas.
The figure shows the functional logic diagram of the “navigation” modes.
There are two controls for automatic packaging cycle: STANDARD and MULTILEVEL CONTROL (from the “layer home”
page).
MULTILEVEL CONTROL allows breaking down the product height in 5 different levels with adjustable thickness and,
for each one of them, it is possible to adjust film stretch, pre-stretch (only on motorised carriages), reinforcement
wrapping turns, machine rotation speed and carriage speed.
Each one of the 5 levels can be set with values depending on the carriage movement direction, namely also with different
values for upstroke and downstroke.
No.
Name
Description of the function
1
“Home” page
The page is displayed upon the activation of the
reset control.
The page displays the wrapping values currently
in use and grants
access to the other pages.
1.1
“Layer home” page
The page is displayed upon the activation of the
control on the right
of the various recipes from the “recipes” page.
The page displays the wrapping values currently
in use and gives access to the other pages
2
“Manual handling” page.
The page displays the controls to activate the
film carriage movement in “manual mode”.
3
"Recipes" page
The page displays the controls to activate the
concerned recipe.
4
“Wrapping cycle” page
The page displays the controls to activate the
wrapping cycle
5
“General parameters” page
The page displays the controls to program the
machine set-up parameters
6
“Production counters (pallets)” page
The page displays the controls to check the
quantity (partial and total) of the pallets made
7
“(H.M.I.) enabling” page
The page displays the controls to customise the
user interface operating mode (only visible with
“machine operator” user)
8
“Change password” page
The page displays the controls to change the
password to access protected functions
9
“Enter password (user login)” page
The page displays the controls to enter the
password (relating to the selected user) to
access the protected functions.
10
“Manuals” page
The page displays the controls for accessing the
user manual and the on-screen spare parts
catalogue.
For details on the listed pages, see the description in the specific paragraph.
