INFORMATION ABOUT THE USE
Danger - warning
The operation must be performed by one operator only.
The operation must not be performed by more than one operator.
Operating modes different from described ones.
Proceed as indicated.
1.
Stop the machine (see paragraph “Machine safe stop”).
2.
The operator must insert the film inside the rollers by hand, making it pass through the roller cone area (A),
following the path engraved on the carriage (B).
Important
Unwind the film following the path engraved on the film carriage plate.
“FRD for mesh” film carriage.
Unwind the film as shown in the relevant plate.
3. Pull the cord outwards.
− The film automatically moves down to the roller and covers it over its entire length.
To allow film or mesh routing between rollers and unwinding on carriages of "FRD" type, it is necessary
to unlock the brake by turning the handwheel (C) to pos. "0".
