Robopac ROBOT S7 - 5.2.2. P3 GS REEL CARRIAGES FOR CHANGING PRE-STRETCH RATIOS

ENG
INFORMATION ON ADJUSTMENTS
47
5.2.2. "P3GS” REEL CARRIAGES FOR CHANGING PRE-STRETCH RATIOS
Proceed as follows.
1. Open the door (A).
2. Lift switch (B) until reaching the requested value (250/0/150 – 300/0/230).
Important
To select a higher pre-stretch, place the selector all the way down; to set a lower pre-stretch, place the
selector all the way up.
Set the selector in the centre to have a pre-stretch of 0.
3. Close the door (A).
Important
The correct value is the one at the bottom
