Robopac ROBOT S7 - 5.6. FEELER THRUST ADJUSTMENT

50
INFORMATION ON ADJUSTMENTS
ENG
5.6. FEELER THRUST ADJUSTMENT
Proceed as follows.
1. Perform “machine safe stop”.
2. Lower the rudder (A).
3. Lift the hood (B).
4. Grasp the lever (C).
5. Connect the lever (C) to the tensioner (D).
6. Adjust the tensioner (D) following its path.
7. Disconnect the lever (C) from the tensioner (D).
8. Put the lever (C) away.
9. Lower the hood (B).
10. Raise the rudder (A).
