Roche Diagnostics
Operator’s Manual · Version 3.4 B-31
Cedex Bio analyzer 5 Daily operation
Preparing the system
a To prepare the cuvettes
Checking the cuvette status
1
Check the color of the cuvette segment buttons.
You can refresh the cuvette screen by pressing . (If there were pending
orders, this would also start their processing.)
Interpreting the screen The number in the button indicates how many cuvettes are free to be used.
Replacing cuvette segments
2
Press a segment button.
A screen is displayed, informing you that the system is ready for cuvette handling.
3
Wait for the main cover LED to turn green.
4
Open the main cover.
5
Remove the segment and treat it as biohazardous waste.
6
Insert a new cuvette segment.
7
Press to confirm the replacement.
(Press if you removed the segment without replacing it.)
Icon Meaning Possible actions
All cuvettes are used. Replace the segment.
Up to two cuvettes are free to be used.
More than two cuvettes are free to be
used.
No action is currently required.
Incorrect results due to scratched or soiled cuvettes
Scratches and impurities on the cuvettes distort the measurements.
Do not touch the cuvettes and make sure they do not touch other items when handling
them.
