Roche Diagnostics
A-52 Operator’s Manual · Version 3.4
3Hardware Cedex Bio analyzer
Hardware overview
Cleaner bottle
The cleaner bottle is positioned on the external fluid rack. It is designed to be
replaced when empty.
Level monitoring for the cleaner bottle is based on the number of cleaning and
pipetting actions that were performed.
When delivered, the bottle has a white cap. During installation, this is replaced by a
red cap with tubing attached to it (tubing adapter).
The cleaner bottle is connected by tubing to:
o Syringe assembly
o Probe
e
See Connecting and disconnecting the external fluid containers on page B-137.
See Checking the status of the external fluid containers on page B-17.
A Tubing adapter B Cleaner bottle
Figure A-20 Cleaner bottle
