Roche Diagnostics
A-86
Operator’s Manual · Version 3.4
4Software Cedex Bio analyzer
Key screens
Key screens
The main screen is divided into tabs. These tabs represent distinct work areas.
f The Overview tab is your main work area when performing the daily routine tasks.
o Use the Wor kpla ce to gain information on orders and the corresponding results.
You can also start the lot handling functions from this tab.
o Use the Utilities tab to perform tasks that are not normally part of the routine
analysis workflow. Typically, these would be administration and maintenance
tasks.
The following sections describe the key screens of these tabs and point out the main
tasks you can perform on them.
Overview tab
The Overview tab is your main work area when performing the daily routine tasks.
Show details about the order for this sample.
STAT Define STAT orders.
Order Define routine orders.
Te sts Check the status of the currently installed tests.
The screen representations shown in this chapter and throughout this manual are for illus-
trative purposes only. The screens do not necessarily show valid data.
A Tube icons
B Status of current order processing
C Buttons
D System status button
Figure A-49 Overview tab
