Roche Diagnostics
Operator’s Manual · Version 3.4 A-61
Cedex Bio analyzer 3Hardware
Hardware overview
Printer
The Cedex Bio analyzer has a built-in thermal printer with a 112 mm paper roll. The
printer is used for example for printing placement lists, results, maintenance action
instructions, and status information on various items such as the loaded tests.
e
See maintenance action Refilling printer paper on page B-132.
See To clear the paper jam on page E-46.
A Panel release button
B Paper slot
C Printer panel
Figure A-31 Printer
