Roche Diagnostics
D-30
Operator’s Manual · Version 3.4
9 General maintenance Cedex Bio analyzer
Maintenance actions
6
Move the transfer head to its leftmost position.
7
Open and remove the right service flap.
8
Remove the sample tray.
Removing the rotor
9
Remove the right side cover and loosen the display fixation screw (A).
10
Tilt forward the display.
11
Move transfer head to its rightmost position.
12
Remove the upper rotor shell.
