Appendix B Module Tag Definitions
Eventx.EventNumber DINT Running count of events, which increments by one each new
time event. The originator sets the Event Number Ack to the
Event Number to acknowledge receipt of the event. When
the EventNumber reaches it maximum value and rolls over it
is to roll over to 1, not 0.
All values.
Eventx.EventTimestamp LINT The time the event occurred. All positive values.
Eventx.CounterxxDone BOOL When set, indicates the corresponding counter Done bit
(rising or falling depending on configuration) triggered the
event.
• 0 = Corresponding counter Done bit did not
trigger the event
•1 = Corresponding counter Done bit triggered the
event
Eventx.PtxxData BOOL When set, indicates the corresponding data value (rising or
falling depending on configuration) triggered the event.
• 0 = Corresponding data value did not trigger the
event
• 1 = Corresponding data value triggered the event
Eventx.CounterxxFault BOOL When set, indicates that the corresponding counter had a
fault indicated when the event occurred.
• 0 = Corresponding counter did not have a fault
indicated when the event occurred
• 1 = Corresponding counter did have a fault
indicated when the event occurred
Eventx.Fault BOOL Detects whether the signal is good data. The fault is set to 1
by the originator when the connection is lost.
• 0 = Good
•1 = Bad
Table 39 - 5094-IB16 Module Event Input Tags
