164 Rockwell Automation Publication 5094-UM001E-EN-P - April 2020
Appendix B Module Tag Definitions
Eventxx.EventTimestamp LINT The time the event occurred. All positive values.
Eventxx.CounterxxDone BOOL When set, indicates the corresponding counter Done bit
(rising or falling depending on configuration) triggered the
event.
• 0 = Corresponding counter Done bit did not
trigger the event
•1 = Corresponding counter Done bit triggered the
event
Eventxx.PtxxData BOOL When set, indicates the corresponding data value (rising or
falling depending on configuration) triggered the event.
• 0 = Corresponding data value did not trigger the
event
• 1 = Corresponding data value triggered the event
Eventxx.CounterxxFault BOOL When set, indicates that the corresponding counter had a
fault indicated when the event occurred.
• 0 = Corresponding counter did not have a fault
indicated when the event occurred
• 1 = Corresponding counter did have a fault
indicated when the event occurred
Eventxx.PtxxFault BOOL Detects whether the signal is good data. The fault is set to 1
by the originator when the connection is lost.
• 0 = Good
•1 = Bad
Table 47 - 5094-IB32 Module Event Input Tags
Name Data Type Definition Valid Values
