Rockwell Automation Allen-Bradley Dialog Plus 1503D User Manual

Serial Communications 8-27
1560D-UM051D-EN-P – February 2005
DeviceNet Examples Example #1 • SLC 500 Controller with Explicit Messaging
This example demonstrates discreet control of the SMC Dialog Plus
controller in addition to use of the explicit messaging function for
transferring parameter data to an SLC500. The DeviceNet Manager
(revision 3.001) software is used in this example for network and node
configuration. RSView™ is used as the man-machine interface in this
example. Many of the selections shown are example specific. Some changes
by the user may be necessary to apply the concepts of this example to a
specific application.
System Configuration
3
11
21
12
22
13
23
14
24
15
25
16
26
17
27
18
28
19
29
20
30
SLC 5/04
1747-SDN Scanner
DeviceNet Trunk
SMC Dialog Plus Controller
L1
1
L2
L3
1203-GK5
Communication Module
Bulletin 1202 SCANport Cable
3
11
21
12
22
13
23
14
24
15
25
16
26
17
27
18
28
19
29
20
30
SLC 5/04
1747-SDN Scanner
DeviceNet Trunk
SMC Dialog Plus Controller
L1
1
L2
L3
1203-GK5
Communication Module
Bulletin 1202 SCANport Cable
Notes:
1) 1747-SDN scanner firmware revision 3.01 or later required.
2) 1203-GK5 module firmware revision 1.9 or later required.
