Programming 4-5
1560D-UM051D-EN-P – February 2005
Password Password protection lets the user limit access to the programming system
of the SMC Dialog Plus™. This feature is disabled with a setting of 0
(factory set default). To modify the password or login after a password is
programmed, complete the procedure below.
Note: If you lose or forget the password, contact your nearest Rockwell
Automation sales office. You can also call Rockwell Automation
Medium Voltage Product Support at 1-519-740-4790 for assistance.
Search The Search mode allows the user to view only those parameters that have
settings other than the factory default values. This mode is only available
when using Bulletin 1201 human interface module.
Description Action Display
——
STOPPED
0.0 AMPS
1. Press any key to go from the status
display to the Choose Mode menu.
CHOOSE MODE
DISPLAY
2. Scroll with the Up/Down keys until the
Password option appears.
CHOOSE MODE
PASSWORD
3. Press the Enter key to access the
Password menu.
PASSWORD
MODIFY
Options: Login, Modify,
Logout
4. Press the Enter key.
ENTER PASSWORD
_ _ _ _ _
5. Press the Up/Down keys to enter the
desired number. If you are modifying
the password, make a note of it as
displayed.
ENTER PASSWORD
# # # # #
6. Press the Enter key after you have
completed modifying the password.X
CHOOSE MODE
PASSWORD
X After you have completed the programming process, re-enter the Password mode to logout. This will eliminate
unauthorized access to the programming system.
To Next Page
