2-14 Installation
1560D-UM051D-EN-P – February 2005
Human Interface Module The Bulletin 1201 human interface modules may be used to program and
control the SMC Dialog Plus controller. The human interface modules
have two sections: a display panel and a control panel. The display panel
duplicates the two-line, 16-character, backlit LCD display and programming
keypad on the front of the SMC Dialog Plus controller. Refer to Chapter 4
for a description of programming keys; refer to Appendix C for a listing
of human interface module catalog numbers that are compatible with the
controller.
The control panel provides the operator interface to the controller. The
keys that provide start and stop control are described below.
Start
The green start button begins motor operation.
Stop
The red stop button halts motor operation.
Jog
The jog button is active only when a control option is present.
Pressing the jog button will initiate the option maneuver
(for example: Pump Stop)
The Bulletin 1201 human interface module's stop push
button is not intended to be used as an emergency stop.
Such usage may result in severe injury or death. Refer to
the applicable standards for emergency stop requirements.
All other controls available with the various human interface modules
are non-functional with the MV Dialog Plus™ controller.
