7-4 Options
1560D-UM051D-EN-P – February 2005
Option Parameter Range
SMB Smart
Motor Braking
SMC Option
This parameter identifies the type of control
present and is not user programmable.
SMB Braking
Braking Current
Allows the user to program the intensity of
the braking current applied to the motor.
0–400% of full load current
SMC Option
This parameter identifies the type of control
present and is not user programmable.
Slow Speed Brake
Slow Speed Select
Allows the user to set the slow speed that
best fits the application.
Low: 7%
High: 15%
Slow Speed
with Braking
Slow Accel Current
Allows the user to program the required
current to accelerate the motor to slow
speed operation.
0–450% of full load current
Slow Running Current
Allows the user to program the required
current to operate the motor at the slow
speed setting.
0–450% of full load current
Braking Current X
Allows the user to program the intensity of
the braking current applied to the motor.
0–400% of full load current
X All braking/stopping current settings in the range of 1–100% will provide 100% braking current to the
motor.
Y Slow speed running is not intended for continuous operation due to reduced motor cooling. The two
starts per hour limitation also applies to slow speed operation.
Control Wiring for Refer to Figure 1-18(c) or 1-18(d) on pages 1-24 and 1-25 respectively
SCANport Control for the applicable wiring diagram to achieve start-stop control via the
SCANport.
Programming Parameters
(cont.)
