Options 7-3
1560D-UM051D-EN-P – February 2005
Programming Parameters The following table outlines the option-specific parameters that are
provided with each control option. These parameters are in addition to
those already discussed in the Basic Setup, Advanced Setup, Metering, and
Calibration groups. Diagrams supporting the options described below are
shown later in this chapter.
Option Parameter Range
Soft Stop
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Soft Stop
Soft Stop Time
Allows the user to set the time period
for the soft stopping function.
0-60 seconds X
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Pump Control
Pump Stop Time
Allows the user to set the time period
for the pump stopping function.
0–120 seconds X
Pump
Control

Starting Mode
Allows the user to program the SMC
Dialog Plus controller for the type of
starting that best fits the application.
Pump Start, Soft Start,
Current Limit Start
SMC Option
This parameter identifies the type of
control present and is not user
programmable.
Preset Slow
Slow Speed Select
Allows the user to program the slow
speed that best fits the application.
Low: 7% – forward; 10% – reverse
High: 15% – forward; 20% – reverse
Preset Slow
Speed
XY
Slow Speed Direction
This parameter programs the slow
speed motor rotational direction.
Forward, Reverse
Slow Accel Current
Allows the user to program the
required current to accelerate the
motor to slow speed operation.
0–450% of full load current
Slow Running Current
Allows the user to program the
required current to operate the motor
at the slow speed setting.
0–450% of full load current
X Thermal capacity limits must not be exceeded. The base rating for MV Dialog units is 30 seconds
maximum. Consult factory if settings over thirty seconds are required. The base rating of the MV
Dialog Plus is two starts (or one start/stop combination per hour), thirty seconds maximum for each
operation. A stopping operation counts as a start for purposes of thermal capacity calculations.
 Slow speed running is not intended for continuous operation due to reduced motor cooling. The two
starts per hour limitation also applies to slow speed operation.
 Refer to Application Considerations on page 1-13.
