A-6 Parameter Information
1560D-UM051D-EN-P – February 2005
Table A.2
Parameter Text/Display Unit Cross-Reference (cont.)
Parameter Number Description Setting Text Display Unit
A0
B1
C2
D3
E4
F5
G6
H7
J8
K9
M11
N12
P13
R14
S15
T16
U17
72 Motor Code Letter
V18
None 0
20 1
180 2
74 Converter Rating
630 3
5:5 0
50:5 1
75:5 2
100:5 3
150:5 4
200:5 5
250:5 6
300:5 7
400:5 8
500:5 9
600:5 10
700:5 11
800:5 12
1000:5 13
75 CT Ratio
1200:5 14
Manual 0
88 Overload Reset
Auto 1
