Installation
Perform the installation duties correctly. Errors may
cause commissioning delays, equipment damage or
personal injury.
Important: For the 1503D, refer to applicable documentation from OEM
installation, grounding, interlocking and wiring. This manual should be
utilized in conjunction with the OEM supplied documentation, and is
suitable for commissioning, programming, calibration, metering, serial
communications, diagnostics, troubleshooting, and maintenance of a
standard solid-state controller.
Receiving It is the responsibility of the user to thoroughly inspect the equipment
before accepting the shipment from the freight company. Check the item(s)
received against the purchase order. If any items are damaged, it is the
responsibility of the user not to accept delivery until the freight agent has
noted the damage on the freight bill. Should any concealed damage be
found during unpacking, it is again the responsibility of the user to notify
the freight agent. The shipping container must be left intact and the freight
agent should be requested to make a visual inspection of the equipment.
Safety and Codes The Canadian Electrical Code (CEC), National Electri-
cal Code (NEC), or other local codes outline provisions
for safely installing electrical equipment. Installation
MUST comply with specifications regarding wire type,
conductor sizes, branch circuit protection, interlocking
and disconnect devices. Failure to do so may result in
personal injury and/or equipment damage.
Unpacking and Inspection After unpacking the material, check the item(s) received against the bill of
lading to ensure that the nameplate description of each item agrees with
the material ordered. Inspect the equipment for physical damage, as stated
in the Rockwell Automation Conditions of Sale.
Remove all packing material, wedges, or braces from within the controller.
Operate the contactors and relays manually to ensure that they operate freely.
Store the equipment in a clean, dry place if it will not be installed immediately
after unpacking. The storage temperature must be between -20°C and 75°C
(-4°F and 167°F) with a maximum humidity of 95%, non-condensing, to
guard against damage to temperature sensitive components in the controller.
Chapter 2
1560D-UM051D-EN-P – February 2005
A T T E N T I O NA T T E N T I O N
A T T E N T I O NA T T E N T I O N
