Metering
Overview While the SMC Dialog Plus™ controller operates your motor, it also
monitors several different parameters, providing a full function metering
X
package.
Viewing Metering Data To access the metering information, follow the procedure below:
Description Action Display
––
AT SPEED
###.# AMPS
1. Press any button to access the
Choose Mode menu.
CHOOSE MODE
_ _ _ _ _ _
2. Scroll with the Up/Down keys until
the Display option is shown.
CHOOSE MODE
DISPLAY
3. Press the Enter key to select the
Display option.
CHOOSE GROUP
_ _ _ _ _ _
4. Scroll with the Up/Down keys until
the Metering option is displayed.
CHOOSE GROUP
METERING
5. Press the Enter key to access the
Metering group.
X Refer to page 1-10 for details on the metering functions.
