Commissioning Procedures 3-3
1560D-UM051D-EN-P – February 2005
Preliminary Check Ensure that all sources of power are isolated and locked
out before working on installed equipment. Verify that
all circuits are voltage free using a hot stick or
appropriate voltage measuring device. Failure to do so
may result in severe burns, injury or death.
A. Verify correct power cable phase sequencing, and that connections are
tight.
B. Verify power fuse ratings and condition.
C. Verify control fuse ratings and condition.
D. Check that power cable installation has not damaged components, and
that electrical spacings have not been reduced.
E. Check that fibre-optic cables are fully seated in their connectors.
F. Check that circuit board plug connectors are installed and fully
inserted in their sockets.
G. Check that the cooling fan (if supplied) is secured and the rotor is not
obstructed.
H. Verify integrity and operation of all interlocks.
I. In the case of the 1503D, verify wiring and perform all tests in
conjunction with OEM documentation.
Programming MV Dialog Plus™ Module
Refer to Chapter 4 for programming procedures.
The default factory settings are as shown in Appendix A.
Settings may be different on engineered orders, or when option modules or
customer requirements dictate different settings.
Important: The module should be programmed with an understanding of
how the SMC functions, and the characteristics of the motor and driven
load. Inappropriate settings may elicit unexpected results such as lack of
acceleration torque or full-voltage starting. For Pump Control applications,
refer to Application Considerations on page 1-13.
If the factory settings are not suitable for the application, program the
module to meet the application requirements. Contact your local Rockwell
Automation representative or the factory if assistance is required.
