Rockwell Automation Allen-Bradley Dialog Plus 1503D User Manual

8-10 Serial Communications
1560D-UM051D-EN-P – February 2005
Remote I/O Examples (cont.) Example #2 – SLC 500 Controller with Block Transfer
This example demonstrates a block transfer of the SMC Dialog Plus™
controller's metering group (parameters 1-11) to an SLC 500. Many of the
selections shown are example-specific. Some changes by the user may be
necessary to apply the concepts of this example to a specific application.
System Configuration
SLC 5/02 or higher 1747-SN Scanner
Remote I/O Link
SMC Dialog Plus
Controller
1203-GD1
Rem I/O
Rem I/O STS
Rem I/O ACT
Health
SCANbus STS
FAULT
2
SH
1
V+
V-
L1
1
L2
3
L3
5
11
21
12
22
13
23
14
24
15
25
16
26
17
27
18
28
19
29
20
30
G
Communication Module
Bulletin 1202 SCANport Cable
1747-SN Series B Scanner
