Calibration
Overview The Calibrate programming group allows the user to set parameters to
calibrate the controller to the connected motor. It is important to correctly
input the data to achieve the best performance from your controller.
For overload protection, it is critical that the data be
entered as it appears on the motor nameplate. Failure to
do so may result in equipment damage.
Motor Data Entry In the Program mode, enter the correct values into the Calibrate group:
Parameter Option Display
Overload Class
The factory default setting disables
overload protection. To enable it, enter the
desired trip class in this parameter. See
pages 1-5 and 1-6 for further details and
trip curves.
Off, 10, 15,
20, 30
OVERLOAD CLASS
—
Overload Reset
Allows the user to select either a manual or
auto reset after an overload fault.
Manual, Auto
OVERLOAD RESET
MANUAL
Motor HP Rating XY
Enter the value from the motor’s
nameplate.
0.0 – 6,533.5 hp
MOTOR HP RATING
#### HP
Motor kW Rating XY
Enter the value from the motor’s
nameplate.
0.0 – 6,553.5 kW
MOTOR KW RATING
#### KW
Line Voltage X
Enter the system voltage in this parameter.
This must be done to ensure optimum
motor performance and correct operation
of undervoltage and overvoltage protection.
1 – 9,999 V
LINE VOLTAGE
#### VOLTS
Motor FLC X
Enter the value from the motor’s nameplate.
1.0 – 999.9 A
MOTOR FLC
###.# AMPS
Service Factor
Enter the value from the motor’s nameplate.
0.01 – 1.99
SERVICE FACTOR
#.##
X Refer to the SMC Dialog Plus Controller nameplate for maximum ratings. Exceeding these could
result in damage to the controller.
Y The controller’s programming system will not allow both HP and kW values to be programmed.
Chapter 5
1560D-UM051D-EN-P – February 2005
A T T E N T I O NA T T E N T I O N
