Appendix B
Spare Parts
1560D-UM051D-EN-P – February 2005
Table B.1
Bulletin 1503D • 1000-1500 Volt, 180/360 Amp, 6-device
Qty per controller Description Part Number
180 A
6 Individual SCR, 5STP04D5200 (matching not required) 80156-815-61-R
360 A
6 Individual SCR, 5STP08G6500 (matching not required) 80156-894-71-R
Common Components
80165-898-52
3 Gate Driver Board (2 devices)
80165-898-55
1 IGDPS Board 80026-044-02
800 – 1000 V 80165-938-51
1001 – 1300 V 80165-938-52
1 Voltage Feedback Circuit Board
1301 – 1500 V 80165-938-53
120 Volt 80187-131-51
1
MV SMC Interface Circuit Board
Assembly – Series B
230 Volt 80187-131-53
Brick type 80025-871-04
3
Snubber Resistor 60 ohm,
10%, 500 W
Wire wound type 80025-588-02
1000 V, 1.0 µF 80025-812-01
3
Snubber Capacitor
(4.5 kV peak)
1300-1500V, 0.68 µF 80025-812-02
3 Sharing Resistor, 32.5 k, 225 W, Two 2.5 k Tap 80025-753-01
2.5 m 80025-549-03
9 Fiber-optic Cable
5.0 m 80025-549-01
120 V AC (North America) 80187-051-51
1
Test Power Supply
Universal 80187-245-51
If desired, a complete factory assembled SCR/heatsink assembly with snubber resistor and capacitor can be purchased rather than
individual SCRs. See table below for part numbers :
Qty per controller Description Part Number
3 180 Amp, 1000 Volt Controller 80157-863-55
3 360 Amp, 1000 Volt Controller 80157-863-56
3 180 Amp, 1300V and 1500V Controller 80157-863-54
3 360 Amp, 1300V and 1500V Controller 80157-863-52
Requires a thin film of electrical joint compound between base and mounting surface. Available with SCR replacement parts
or separately as Part Number 80025-783-51.
Reference only. 1503D – For OEM products, refer to OEM-supplied documentation for specific spare parts list.
1560/1562D are Allen-Bradley manufactured starters. Refer to Service Manual for specific spare parts list.
Used when options 13XA (Soft Stop) or 13XB (Pump Control) are not provided.
Used when options 13XA (Soft Stop) or 13XB (Pump Control) are provided.
