Appendix A
Parameter Information
1560D-UM051D-EN-P – February 2005
Table A.1
Parameter List
Group Parameter Description
Parameter
Number
Display
Units
Scale
Factor
Minimum Maximum
Default
Setting
User
Setting
Voltage Phase A-B 1 Volts 1 – – – –
Voltage Phase B-C 2 Volts 1 – – – –
Voltage Phase C-A 3 Volts 1 – – – –
Current Phase A 4 Amps 10 – – – –
Current Phase B 5 Amps 10 – – – –
Current Phase C 6 Amps 10 – – – –
Wattmeter Y 7MW10– – – –
Kilowatt Hours Y 8MWh1– – – –
Elapsed Time 9 Hours 1 – – – –
Power Factor Y 10 – 100 – – – –
Metering X
Motor Thermal Usage 11 % 1 – – – –
Clear Fault 18 – – No, Yes No –
Fault Buffer #1 X 19 – 1 – – – –
Fault Buffer #2 X 20 – 1 – – – –
Fault Buffer #3 X 21 – 1 – – – –
Fault Buffer #4 X 22 – 1 – – – –
Faults
Fault Buffer #5 X 23 – 1 – – – –
SMC Option X 14 – –
Standard, Soft Stop, Pump Control,
Preset Slow Speed Smart Motor Braking,
or Slow Speed with Braking
Starting Mode 28 – – Soft Start, Current Limit Soft Start –
Ramp Time #1 30 Seconds 1 0 30 10
Initial Torque #1 31 % LRT 1 0 90 70
Current Limit Level 34 % FLC 1 50 600 50
Kickstart Time 35 Seconds 10 0.0 2.0 0.0 (Off)
Stall Delay 37 Seconds 10 0.0 10.0 0 (Off)
Energy Saver Z 38 – – Off, On Off
Aux. Contacts 1 & 2 39 – 1 Normal, Up-to-speed Up-to-speed
Aux. Contact 3 40 – – Normal, Fault
Fault (1560D)
Normal (1562D)
Contact 3 Configuration 41 – – N.O., N.C.
N.C. (1560D)
N.O. (1562D)
Basic Setup
Parameter Mgmt. 17 – –
Ready, Default Init.
Recll Frm EE, Store in EE
Ready
X Read-only capability.
Y The Series A SMC Dialog Plus™ module does not provide power functions when used in the MV Dialog Plus controller.
Z Not available with MV Dialog Plus.
To Next Page
