A-2 Parameter Information
1560D-UM051D-EN-P – February 2005
Table A.1
Parameter List (cont.)
Group Parameter Description
Parameter
Number
Display
Units
Scale
Factor
Minimum Maximum
Default
Setting
User
Setting
Control Options
Soft Stop
Soft Stop Time 42 Seconds 1 0 60 X 0
Pump Control
Starting Mode 28 – –
Soft Start, Current Limit
and Pump Start
Soft Start
Pump Stop Time 42 Seconds 1 0 120 X 0
Preset Slow Speed
Slow Speed Select 44 – – Low, High High
Slow Speed Direction 45 – – Reverse, Forward Forward
Slow Accel. Current 46 % FLC 1 0 450 0
Slow Running Current 47 % FLC 1 0 450 0
SMB Smart Motor Braking
Braking Current 48 % FLC 1 0 400 0
Slow Speed with Braking
Slow Speed Select 44 – – Low, High High
Slow Accel. Current 46 % FLC 1 0 450 0
Slow Running Current 47 % FLC 1 0 450 0
Basic Setup
(cont.)
Braking Current 48 % FLC 1 0 400 0
X Thermal capacity limits must not be exceeded. The base rating for MV Dialog units is 30 seconds max. Consult factory for higher settings.
