Parameter Information A-3
1560D-UM051D-EN-P – February 2005
Table A.1.
Parameter List (cont)
Group Parameter Description
Parameter
Number
Display Units
Scale
Factor
Minimum Maximum
Default
Setting
User
Setting
Dual Ramp 29 – – No, Yes No
Ramp Time #2 32 Seconds 1 0 30 10
Initial Torque #2 33 % LRT 1 0 90 70
Undervoltage Level 52 % Line Voltage 1 0 Y 99 80
Undervoltage Delay 53 Seconds 1 0 99 0
Overvoltage Level 54 % Line Voltage 1 0 199 0 (Off)
Overvoltage Delay 55 Seconds 1 0 99 0
Jam Level 56 % FLC 1 0 999 0 (Off)
Jam Delay 57 Seconds 10 0.0 10.0 0
Unbalance Level 58 % 1 0 25 0 (Off)
Unbalance Delay 86 Seconds 1 0 99 0
Rebalance X 59 – Off, On Off
Underload Level 60 % FLC 1 0 99 0 (Off)
Underload Delay 61 Seconds 1 0 99 0
Phase Reversal 62 – – Off, On Off
Starts per Hour 63 – 1 0 99 2
Restart Attempts 64 – 1 0 5 2
Restart Delay 65 Seconds 1 0 60 0
ETM Reset 15 – – Off, On Off
Advanced
Setup
Parameter Management 17 – –
Ready, Default Init.
Recll Frm EE, Store in EE
Ready
X Not available with MV Dialog Plus.
Y Do not set below 70%.
