A-4 Parameter Information
1560D-UM051D-EN-P – February 2005
Table A.1
Parameter List (cont.)
Group Parameter Description
Parameter
Number
Display Units
Scale
Factor
Minimum Maximum
Default
Setting
User
Setting
Overload Class 36 – – Off, 10, 15, 20 and 30 Off
Overload Reset 88 – – Manual – Auto Manual
Motor HP Rating 79 HP 10 0.0 6,553.5 0.0
Motor kW Rating 80 kW 10 0.0 6,553.5 0.0
Line Voltage 69 Volts 1 0 9999 350 Z
Motor FLC 70 Amps 10 1.0 999.9 1.0
Service Factor 84 – 100 0.01 1.99 1.05
Motor Code Letter 72 – –
A,B,C,D,E,F,G,H,J,K,L,
M,N,P,R,S,T,U and V
G
LRC Ratio 81 – 10 0.0 19.9 0.0
Converter Rating 74 – – None, 20, 180, 630 20
CT Ratio 75 – –
5, 50, 75, 100, 150,
200, 250, 300, 400,
500, 600, 750, 800,
1000, 1200:5
5:5
Calibration 76 – – Off, Activate Off
Enter Calib. Amps 77 Amps
Y
0.01 999.9 0.0
Current Phase A X 4 Amps 10 – – –
Calibrate
Parameter Management 17 – –
Ready, Default Init.
Recll Frm EE, Store in EE
Ready
Factory MV Ratio 12 – – – – 0
[
X Read-only capability.
Y The scale factor is 100 when Motor FLC, parameter 70, has a programmed value of up to 10.0 amps; above 10.0 amps, the scale factor is 10.
Z User to program for system voltage.
[ For Parameter 12 = 0, the MV Ratio is automatically set for common line voltages as follows:
Parameter 69 Voltage Divider Rating MV Ratio
1000-2850 2400 7.08
2851-3730 3300 9.10
3731-5530 4160 13.2
>5530 6900 19.2
Parameter 12 requires a special password to access, but may be changed to allow fo
other voltage divider ratings or to fine tune the voltage display to improve the accuracy.
Available voltage dividers and their MV ratios are as follows:
Voltage Divider Rating MV Ratio
1000 2.62
1300 3.43
1500 5.05
5500 16.4
