Parameter Information A-5
1560D-UM051D-EN-P – February 2005
Table A.2
Parameter Text/Display Unit Cross-Reference
Parameter Number Description Setting Text Display Unit
Standard 0
Soft Stop 1
Pump Control 2
Preset Slow Speed 3
Smart Motor Braking 4
Accu-Stop X 5
14 SMC Option
Slow Speed with Braking 6
Off 0
15 ETM Reset
On 1
Ready 0
Default Init. 1
Recall from EE 2
17
Parameter
Management
Store in EE 3
No 0
18 Clear Fault
Yes 1
Current Limit 0
Soft Start 128 Starting Mode
Pump Start Y 2
No 0
29 Dual Ramp Z
Yes 1
Off 0
10 1
15 2
20 3
36 Overload Class
30 4
Off 0
38 Energy Saver X
On 1
Normal 0
39 Aux. Contacts 1 & 2
Up-to-speed 1
Normal 0
40 Aux. Contact 3
Fault 1
N.O. 0
41 Contact 3 Config.
N.C. 1
Low 0
44 Slow Speed Select [
High 1
Reverse 0
45 Slow Speed Direction \
Forward 1
Off 0
59 Rebalance X
On 1
Off 0
62 Phase Reversal
On 1
X Not available with MV Dialog Plus.
Y Pump Start is only available with the Pump Control option.
Z Dual Ramp is only available with the standard controller.
[ Slow Speed Select is only available with the Preset Slow Speed option.
\ Slow Speed Direction is only available with the Preset Slow Speed option.
